PORON 4701-15 soft seal series provides enhanced surface toughness and reliable, durable materials for use in thinner designs. Designed for superior dust sealing at 6lb/ft3, the PORON 4701-15 soft seal series is the lowest density offering in the PORON product line.

Features

  • Thicknesses available include .53, .75 and 1 mm (.021, .030 and .039 in.)
  • Density of 104 kg/m3 (16 lb/ft3)
  • Increased surface toughness improves yields

Benefits

  • Long term protection and dust sealing
  • Excellent compressibility and conformability
  • Ease of processing

Please see below for a sampling of data for this material formulation. For detailed material information and to use advanced features such as filtering, visit the PORON® Polyurethanes Product Properties Guide.

4701-15-06 4701-30-15
Thickness (Min) (mm) 0.53 4.78
Thickness (Max) (mm) 1.00 12.70
Density ASTM D 3574 Test A (kg/m3) 104 240
Thickness Tolerance (%) +/-10% +/-10%
Compression Force Deflection Typical Value @ 25% (kPa) 2.00 21.0
Compression Set (70°C) Max Value (%) 10.0 10.0
Tensile Strength (kPa) 207
Tensile Elongation % Typical Value ASTM D 3574 (%) 161
Tear Strength (kN/m) 5.0
Temperature Resistance: Recommended Constant Use (°C) 90°
Temperature Resistance: Recommended Intermittent Use (°C) 121°
Temperature Resistance: Embrittlement (°C) -51°
