Benefits

  • Low electrical loss
  • Low moisture absorption
  • Stable dielectric constant (Dk) over wide frequency range
  • Low outgassing for space applications

Products

RT/duroid® 5870 Laminates

  • Dk of 2.33
  • Dissipation factor of .0012 at 10 GHz

RT/duroid® 5880 Laminates

  • Dk of 2.20
  • Dissipation factor of .0009 at 10 GHz

RT/duroid® 5880LZ Laminates

  • Dk of 2.0
  • Lightweight material due to unique filler

RT/duroid® 6002 Laminates

  • Dk of 2.94
  • Electrical and mechanical properties essential for complex microwave structures

RT/duroid® 6006 and 6010.2LM Laminates

  • Dk of 6.15 or 10.2
  • Tight thickness control for size reduction

RT/duroid® 6035HTC Laminates

  • Dk of 3.6
  • Thermal conductivity of 1.44 W/m/K, almost 2.4 times standard RT/duroid® products

RT/duroid® 6202 Laminates

  • Dielectric constant (Dk) of 2.94 ±0.04 to 3.06 ±0.04 depending on thickness
  • Excellent dimensional stability due to added woven glass reinforcement

RT/duroid® 6202PR Laminates

  • Dielectric constant (Dk) of 2.94 ±0.04 or 2.98 ±0.04 depending on thickness
  • Mechanically reliable and electrically stable for planar resistor applications

Applications

View current applications of this product line.

Antenna Systems

Antenna Systems

Communications
Systems

Communications Systems
